PTO Pin Round

Description

About Pto Pin

Category: PTO Driveline Components

Brand: Jrs Farm Parts

The PTO pin — also known as a PTO yoke pin, driveline shear pin, or quick-release pin — is the fastener that secures the power take-off shaft to the splined output shafts of the tractor and the input shaft of the implement. Despite its small size, this pin is a safety-critical component: if it fails or disengages during operation, the PTO shaft can separate from the tractor or implement while spinning at 540 or 1,000 RPM, creating an extremely dangerous situation for the operator and anyone nearby. Even a partial disengagement can damage splines on both the PTO shaft yoke and the tractor or implement shaft, leading to expensive repairs that far exceed the cost of a quality pin.

Jrs Farm Parts manufactures PTO pins at our ISO-certified facility in Ludhiana, India, to dimensional and material specifications suited to the demanding conditions of agricultural PTO service. Each pin is produced from alloy steel and heat-treated to achieve the hardness and shear strength needed for its retention function without becoming so brittle that it fractures under the vibration and cyclic loading typical of driveline operation. The heat treatment process is followed by surface finishing that provides corrosion resistance for equipment that is frequently stored outdoors or operated in wet conditions.

Our PTO pin range includes both round and square cross-section variants. Round pins are the traditional standard, used across decades of tractor and implement production from multiple manufacturers. Square cross-section pins provide a larger bearing surface within the yoke retaining groove, reducing localized contact stress and offering improved retention in applications where PTO shafts experience significant axial movement during operation — common with implements that follow uneven ground contours. Both styles incorporate a spring-loaded retention mechanism: a wire-form or flat-spring retainer that snaps over the end of the pin after insertion, preventing the pin from working its way out under vibration.

Multiple diameters are available to match the range of PTO yoke sizes found on equipment from compact tractors through to large row-crop and articulated machines. Each pin is supplied with its matched retention spring, and bulk-packaged options are available for dealers and repair shops that stock these pins as high-turnover service items.

For American agricultural parts distributors, equipment dealers, and farm repair shops, Jrs Farm Parts PTO pins deliver what matters most in this category: consistent dimensional accuracy for proper yoke fit, appropriate hardness for reliable retention, and spring tension that holds through long service intervals — all at export-direct pricing from our Ludhiana manufacturing operation. ISO-certified production processes and batch-level quality verification support the dependable supply that US buyers require from their international sourcing partners.
